HBL2823

30A, 3 Phase Y 277/480V AC; 4 Pole, 5 Wire Grounding Insulgrip® Connector

Features

Ribbed nylon housing provides a secure grip and impact and chemical resistance.

Superior cord grip design protects terminations from excess strain.

Clear, funnel shaped wire entry for ease of termination.

Integral dust shield protects wiring chamber from dust or contaminants.

咨询热线：

产品描述

Description	Cord Diameter	UPC	Catalog Number
Black and white nylon.	.35"-1.15" (9-29)	78358503970	HBL2823

Listed to UL 498

Fed.Spec. W-C-596

Certified to CSA C22.2 No.42

Housing / Cord Clamp	Nylon
Terminal Retainer	Clear polycarbonate
Contacts	Brass
Terminal Screws	#10-32 Brass (Phillips / Slotted / Robertson)
Terminal Clamp	Cold rolled steel – nickel plated
Assembly Screws	Steel - nickel plated

Electrical
Current Interrupting	Certified for current interrupting at full rated current
Dielectric Voltage	Withstands 2,000V minimum
Mechanical
Terminal Accommodation	#16 AWG - #8 AWG solid or stranded copper wire only.
Terminal Identification	Terminals identified in accordance with UL 498
Environmental
Flammability	HB or better per UL94 or CSA 22.2 No. 0.6
Operating Temperatures	Maximum Continuous 75°C Minimum -40°C (w/o impact)
