General Description

 SFGMOS®  MOSFET is based on Oriental Semiconductor’s unique device design to achieve low RDS(ON) , low gate charge, fast switching and excellent avalanche characteristics. The  low Vth  series is specially designed to use in synchronous rectification power systems with low driving voltage.



Features

  • Low RDS(ON) & FOM
  • Extremely low switching loss
  •  Excellent stability and uniformity

Applications

  • PD charger
  • Motor driver
  • Switching voltage regulator
  • DC-DC convertor
  • Switched mode power supply



Key Performance Parameters

Parameter

Value

Unit

VDS, min @ Tj(max)

100

V

ID, pulse

45

A

RDS(ON), max @ VGS =10V

75

Qg

6.5

nC



Marking Information

Product Name

Package

Marking

SFG15N10DF

TO252

SFG15N10D



Package & Pin Information







Package

TO-252

Cfg.

N

VDS (V)

700

VGS (V)

30

ID (A) && Tc=25℃

17

Vth_typ(V)

3.9

Ron (Ω) && 10V

0.25

Ron (Ω) && 4.5V

0.17
